Thermal Shipping Insulating Container Liners

  • Thermal Shipping Insulating Container Liners
  • Thermal Shipping Insulating Container Liners
  • Thermal Shipping Insulating Container Liners
  • Thermal Shipping Insulating Container Liners
  • Thermal Shipping Insulating Container Liners
Model No.︰LN-CTL
Brand Name︰weico
Country of Origin︰China
Unit Price︰US $ 147 / pc
Minimum Order︰20 pc
Share on:

 Total 17 Related Items
Prev89101112Next

Product Description

Speicification:

1. Structure:Alu/PE/Aerogel/woven fabric/PA/Alu/PET
2. weight: 180-190g/M2
3. Thickness: 0.2mm
4. Size: 6*2.35*2.35m
        12*2.35*2.35m
        12*2.35*2.70m
5. Moisture Permability: 6.1g/m2--24h
6. Heat reflectivity:96%
7. Temperature resistance: -70ºC/100ºC
8. Oxygen permeability: 101.86×10-6
9. Puncture Strength: 23N
10. Tensile strength Endwise: 370N
11. Tensile strength Broadwise: 360N
12. G.W.: 20GP:18KG;
          40GP:26KG;
          40HQ:29KG


About us:
Ln-weico insulation packaging bag is used for transport packaging, which to provent the products to deteriorate, not affected by ambient temperature and humidity in the transporation.


Matetial:
This product is made of 7layers structure, which is pure aluminum foil for two sides, middle layer is barrier layer. Compared with traditional bubble film and epe, this material is more light and thin and convenient to process. It has high resistance strength, and can be recycled to use.


Application:
It can be widely used in transport packaging with thermal insulation, keep warm and damp proof function. Especially for food, chemical and wine etc. it is more economic, protecting environment and reliable. We can accept the size customizing with different quantity.

Effect:
In summer, when ambient temperature is 39 degree, container inner temperature will arrive 60 degree, but liner bag temperature is just in 40-45 degree, then have 15-20 degree temperature difference.

Payment Terms︰30% deposit, 70% before delivery
